| Type | IPW-25100 | IPW-51100 |
|---|---|---|
| Battery Type | LiFePo4 | LiFePo4 |
| Nominal Voltage | 25.6V | 51.2V |
| Nominal Capacity (Wh) | 2.56KWh | 5.12KWh |
| Nominal Capacity | 100Ah | 100Ah |
| Operating Voltage Range | 20V – 28.8V | 40V – 57.6V |
| Standard Charging Current | 50A | 50A |
| Maximum Continuous Charge Current | 100A | 100A |
| Cut-off Charging Voltage | 28.8V | 57.6V |
| Cut-off Charging Current | 2A | 2A |
| Standard Discharge Current | 50A | 50A |
| Maximum Continuous Discharge Current | 100A | 100A |
| Maximum Pulse Discharge Current | 150A | 150A |
| Cut-off Discharge Voltage | 20V | 40V |
| Cut-off Discharge Current | 2A | 2A |
| Dimensions (mm) | 454 × 410 × 135 | 454 × 585 × 135 |
| Weight (kg) | 27 | 45 |
| Communication Port | RS485 / RS232 / CAN | RS485 / RS232 / CAN |
| Working Temperature (°C) Charge | 0 – 55°C | 0 – 55°C |
| Working Temperature (°C) Discharge | -20 – 60°C | -20 – 60°C |
| IP Rating of Enclosure | IP21 | IP21 |
| Cooling Type | Natural Cooling | Natural Cooling |
| Humidity | 0 – 95% | 0 – 95% |
| Altitude (M) | <2000 | <2000 |
| Shell Material | Metal | Metal |
| Current Limiting Function | Limited 10A | Limited 10A |
| Precharge Function | Enable | Enable |
| Dial-up Add | 4 Green LED | 4 Green LED |
| Design Life | 10+ years | 10+ years |
| Cycle Life | ≥4000 | ≥4000 |
| Authentication Level | IEC + UN 38.3 + MSDS + DGM | IEC + UN 38.3 + MSDS + DGM |
