| Battery Type |
LiFePo4 |
LiFePo4 |
| Nominal Voltage |
25.6V |
51.2V |
| Nominal Capacity (Wh) |
2.56KWh |
5.12KWh |
| Nominal Capacity |
100Ah |
100Ah |
| Operating Voltage Range |
20V – 29.2V |
40V – 58.4V |
| Standard Charging Current |
50A |
50A |
| Maximum Continuous Charge Current |
100A |
100A |
| Cut-off Charging Voltage |
29.2V |
58.4V |
| Cut-off Charging Current |
2A |
2A |
| Standard Discharge Current |
50A |
50A |
| Maximum Continuous Discharge Current |
100A |
100A |
| Maximum Pulse Discharge Current |
150A |
150A |
| Cut-off Discharge Voltage |
20V |
40V |
| Cut-off Discharge Current |
2A |
2A |
| Dimensions (mm) |
480 × 400 × 150 |
460 × 510 × 153 |
| Weight (kg) |
28 |
50 |
| Communication Port |
RS485 / RS232 / CAN |
RS485 / RS232 / CAN |
| Working Temperature (°C) Charge |
0 – 55°C |
0 – 55°C |
| Working Temperature (°C) Discharge |
-20 – 60°C |
-20 – 60°C |
| IP Rating of Enclosure |
IP21 |
IP21 |
| Cooling Type |
Natural Cooling |
Natural Cooling |
| Humidity |
0 – 95% |
0 – 95% |
| Altitude (M) |
<2000 |
<2000 |
| Shell Material |
Metal |
Metal |
| Current Limiting Function |
Limited 10A |
Limited 10A |
| Precharge Function |
Enable |
Enable |
| Dial-up Add |
4 Green LED |
4 Green LED |
| Design Life |
10+ years |
10+ years |
| Cycle Life |
≥4000 |
≥4000 |
| Authentication Level |
IEC + UN 38.3 + MSDS + DGM |
IEC + UN 38.3 + MSDS + DGM |
